Images are for reference only. See Product Specifications for product details
Bourns, Inc. MF-SM200-2-006
PTC RESET FUSE 15V 2A 2SMD
- Manufacturer
- Bourns, Inc.
- Datasheet
- Price
- 0.26
- Stock
- 0
Product Details
- Time to Trip
- 25s
- Resistance - Initial (Ri) (Min)
- 24 mOhms
- Current - Max
- 100A
- Resistance - Post Trip (R1) (Max)
- 85 mOhms
- Mounting Type
- Surface Mount
- Voltage - Max
- 15V
- Package / Case
- 2-SMD
- Type
- Polymeric
- Thickness (Max)
- 0.118" (3.00mm)
- Series
- Multifuse®, MF-SM
- Base Part Number
- MF-SM
- Ratings
- AEC-Q200
- Size / Dimension
- 0.344" L x 0.264" W (8.75mm x 6.71mm)
- Approvals
- cURus, TUV
- Current - Trip (It)
- 5A
- Packaging
- Tape & Reel (TR)
- Height - Seated (Max)
- -
- Part Status
- Active
- Operating Temperature
- -40°C ~ 85°C
- Lead Spacing
- -
- Current - Hold (Ih) (Max)
- 2.5A
